PE5108G - Aten PDU - NRGence Eco PDU Intelligent IP Access '15A/10A 8-Outlet' 1U Metered eco PDU, with Outlet monitoring

ATEN PDU - (PE5108)

Description:

• 1U 8-Outlet eco PDU • Bank level metering ATEN has developed a new generation of green energy power distribution units (PDUs) to effectively increase the efficiency of data center power usage. The PE5108 eco PDUs are intelligent PDUs that contain 8 AC outlets and are available in various IEC or NEMA socket configurations. They provide secure, centralized, intelligent, power management of data center IT equipment (servers, storage systems, KVM switches, network devices, serial data devices, etc.), as well as the ability to monitor the center's health environment via sensors*. Eco PDUs offer real-time power measurement - allowing you to monitor the power status of devices attached to the PDUs, from practically any location via a TCP/IP connection. Eco PDU supports any 3rd party v3 SNMP Manager Software and eco Sensors (Energy Management Software). eco Sensors provides you with an easy method for managing multiple devices, offering an intuitive and user friendly Graphical User Interface that allows you to configure a PDU device and monitor power status of the equipment connected to it. With eco Sensors, the Sensor-enabled eco PDU also offers comprehensive power analysis reports which can separate by departments and locations, providing precise measurements of current, voltage, power and watt-hour in a real-time display. With its advanced security features and ease of operation, the eco PDU is the most convenient, most reliable, and most cost effective way to remotely manage power access for multiple computer installations and allocate power resources in the most efficient way possible. * Sensors are optional accessories. A sensor-enabled installation is required to generate a more complete energy-efficient data and chart. Higher sensor installation density is helpful to generate more accurate data.

Features:

Connections

• Support 10/100Mbit Ethernet Interface
• Support TCP/IP, UDP, HTTP, HTTPS, SSL, DHCP, SMTP, NTP, DNS, Auto Sense, Ping, Telnet..
• Support 2-level account/password security, IP/MAC filter, 128 bit SSL, RADIUS
• Support : eco Sensors, Browser (IE, Firefox, Chrome, Safari)

Metering

• Bank level power metering and monitoring
• Environment Monitoring : support external temperature/temperature & humidity sensors
• Current, voltage, power, power dissipation, temperature, and humidity metering and threshold level

Outlet Switch Control

• Always On

ATEN PDU - (PE5108)

Specification:

ELECTRICAL

Nominal Input Voltage 100 - 120 VAC
Maximum Input Current - 15A Max; 12A(UL de-rated)
Input Frequency - 50-60 Hz
Input Connection - IEC 60320 C14
Input Power - 12496 VA(UL de-rated) - 2300 VA(Max)
Outlet Type - 8 x IEC320 C13
Nominal Output Voltage - 100 - 240 VAC
Maximum Output Current (Outlet) - 12A(UL de-rated) / C13 : 10A(Max)
Maximum Output Current (Bank) - 12A(UL de-rated) / 10A(Max)
Maximum Output Current (Total) - 12A(UL de-rated) / 10A(Max)
Breakers - 1 x 15A Non-Fuse Breaker
Metering - Bank level Current, Voltage, VA , PF and KWh Monitoring
Outlet Switching - NA
Environment Sensor Ports - 2
Metering Accuracy - Voltage Range: 100VAC ~ 250VAC +/-1%
Voltage Range: 100VAC ~ 250VAC +/-1%
Power Range: 100W ~ Maximum Capacity +/- 2%
Current Range: 0.1A~1A +/- 0.1A, 1A~20A +/-1%

PHYSICAL PROPERTIES

Dimensions (L x W x H) - TBD
Weight - TBD
Power Cord Length - 3 m

ENVIRONMENTAL

Temperature (Operating / Storage) - 0 – 50°C / -20 – 60°C
Humidity (Operating & Storage) - 0 – 80% RH, Non-Condensing

COMPLIANCE

EMC Verification - FCC, CE, C-Tick, Others by Request
Safety Verification - cTUVus, PSE, Others by Request

Note: For some of rack mount products, please note that the standard physical dimensions of

WxDxH are expressed using a LxWxH format

CONTENTS

1x PE5108 eco PDU
1x Mounting Kit
1x Power Cord
1x CD-ROM (Manual, eco Sensors Software)
1x User Instructions
